Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125-08B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Valve-Integrated Cylinder SAUF100X125-08B Specifications
- Model: SAUF100X125-08B
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm
- Stroke: 125mm (customizable up to 500mm)
- Operating pressure: 0.05–1.0 MPa
- Port thread: G3/8 (BSPP)
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Ambient temperature: -10℃ to 80℃
- Weight: 6.8kg (excluding accessories)
- Dimensions: 332mm(L) × 122mm(W) × 122mm(H) (at mid-stroke)
- Response time: ≤100ms (valve switching)
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km)
High-torque integrated cylinder-valve unit designed for space-constrained heavy-duty applications. Features anti-rotation piston rod (chrome-plated steel) and magnetic position sensing capability. The aluminum alloy body with hard anodized finish resists chemical corrosion in harsh environments. Includes builtin speed controller and silencer.
- Automated foundry equipment (core shooting machines)
- Heavy press brake tool changers
- Plastic injection molding ejectors
- Automotive welding fixture clamping
- Food processing conveyor diverters
Installation guidelines:
Mount using M8x1.25 mounting bolts (ISO 14839 compliant). Maintain minimum 50mm
clearance around valve exhaust ports. Use locknuts on rod end for vertical
installations. Lubricate with ISO VG32 hydraulic oil if operated below -5℃.
| Property | Property Value |
|---|---|
| sku | SAUF100X125-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
