Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125-10A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X125-10A Valve-Integrated Cylinder Specifications
- Model: SAUF100X125-10A
- Type: Compact cylinder with built-in 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 125mm
- Operating pressure: 0.1–0.9 MPa
- Port size: PT1/4 (G1/4 optional)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Weight: 3.5kg (with magnetic switch)
- Dimensions: 325mm(L) × 118mm(W) × 118mm(H)
- Cushioning: Adjustable air cushion (both ends)
- Seal material: Heat-resistant NBR (-20℃ to 90℃)
- Flow rate: 650 L/min (ANR)
- Response time: ≤20ms (at 0.5MPa)
- Protection rating: IP67 (valve), IP40 (cylinder)
- Mounting type: Basic axial mounting
Integrated pneumatic solution combining cylinder and valve in a single unit, designed for space-constrained automation systems. Features corrosion-resistant aluminum alloy construction with hard anodized piston rod (Cr-Mo steel). Includes built-in magnetic piston for position sensing compatibility. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- High-speed pick-and-place robotic arms
- Plastic injection molding ejectors
- Automotive assembly line clamping devices
- Food packaging machine actuators
- Semiconductor wafer handling systems
Installation note:
Maintain minimum 50mm clearance around valve section for heat dissipation.
Use M5x0.8 mounting screws with 12N·m torque limit. Lubricate through FRL unit
(ISO VG32 equivalent oil, 1 drop/5m³ air). Avoid lateral load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SAUF100X125-10A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
