Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125S-08A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X125S-08A Valve-Integrated Cylinder Specifications
- Model: SAUF100X125S-08A
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: Φ100mm
- Stroke: 125mm
- Operating pressure: 0.1–0.9 MPa
- Port size: PT1/4 (G1/8 optional)
- Voltage options: DC12V/24V, AC110V/220V (coil interchangeable)
- Weight: 3.8kg ±2%
- Dimensions:
- Extended length: 382mm
- Retracted length: 257mm
- Body width: 115mm
- Height with valve: 178mm
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Hard anodized aluminum alloy
- Seals: NBR (standard), optional FKM for high temp
- Operating temperature: -10℃ to 80℃ (standard seals)
- Cushioning: Adjustable pneumatic cushion
- Response time: ≤100ms (at 0.5MPa)
- Protection rating: IP67 (valve section IP65)
Integrated design combines ISO 15552 cylinder with pilot-operated solenoid valve, eliminating external tubing. Features auto-switching manual override and LED status indicator. Optimized for high cycle rates (up to 5Hz continuous operation) with low stick-slip characteristics. Requires 5μm filtered lubricated air (ISO 8573-1 class 3.4.2).
- Automated material handling systems
- Plastic injection molding ejectors
- Automotive assembly clamping units
- Food processing vertical lifts (with food-grade grease option)
- Packaging line diverters
Installation guidelines:
Mount using M10x1.5 mounting bolts (max torque 45N·m). Maintain ≥20mm clearance
around valve section for heat dissipation. Lubricate through air supply (ISO VG32
equivalent) if operating below 1Hz cycle rate.
| Property | Property Value |
|---|---|
| sku | SAUF100X125S-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
