Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125S-08B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Integrated Valve Cylinder SAUF100X125S-08B Specifications
- Model: SAUF100X125S-08B
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 125mm
- Operating pressure: 0.1–1.0 MPa
- Port size: G3/8 (NPT1/2 optional)
- Voltage options: DC12V, DC24V, AC110V, AC220V (50/60Hz)
- Seal material: NBR/PU combination
- Temperature range: -10℃ to 80℃
- Protection rating: IP67 (with optional cover)
- Mounting type: Standard ISO/VDMA mounting grooves
- Weight: 3.7kg (excluding accessories)
- Dimensions: 330mm(L) × 120mm(W) × 122mm(H) (fully extended)
- Cushioning: Adjustable pneumatic cushioning
- Response time: ≤100ms (at 0.5MPa)
Integrated valve-cylinder unit combining a double-acting pneumatic cylinder with direct-mounted 5/2-way solenoid valve, designed for space-constrained automation systems. Features corrosion-resistant aluminum alloy construction with hard anodized piston rod (Cr-Mo steel base). Includes magnetic piston for position sensing compatibility. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- High-speed pick-and-place systems in electronics assembly
- Clamping mechanisms in CNC machining centers
- Material handling gate controls
- Packaging machine ejection systems
- Automated welding fixture positioning
Installation guidelines:
Maintain ≥15mm clearance around valve section for heat dissipation.
Use flexible tubing to absorb vibration. Lubricate through air supply
(ISO VG32 recommended). Avoid lateral forces on piston rod.
Critical parameters:
Maximum side load 45N, maximum piston speed 700mm/s.
Not suitable for continuous duty cycles above 80% without
auxiliary cooling. Replace seals every 5 million cycles in
normal operating conditions.
| Property | Property Value |
|---|---|
| sku | SAUF100X125S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
