Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125S-10B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Valve-Integrated Cylinder SAUF100X125S-10B Specifications
- Model: SAUF100X125S-10B
- Type: Valve-integrated cylinder (5/2-way solenoid valve)
- Bore size: Ø100 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.9 MPa
- Valve type: Pilot-operated with manual override
- Voltage options: DC24V (±10%), AC110V/220V (50/60Hz)
- Port size: PT1/2 (G1/2 optional)
- Cushion type: Adjustable pneumatic cushion (both ends)
- Material: Aluminum alloy cylinder tube, chromium-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP67 (valve), IP40 (cylinder)
- Weight: 5.8 kg (including valve)
- Dimensions: 300mm(L) × 118mm(W) × 135mm(H) (at mid-stroke position)
- Response time: ≤50 ms (valve switching)
- Max piston speed: 50–750 mm/s
High-efficiency combination unit integrating a robust pneumatic cylinder with a 5/2-way solenoid valve, designed for space-constrained automation systems. Features triple sealing structure for leak prevention and corrosion-resistant coating. The built-in valve reduces piping complexity by 60% compared to traditional setups.
- Palletizing robot end-effector actuation
- Injection molding machine ejector systems
- Automotive welding fixture positioning
- Bottle capping machine vertical drives
- CNC machine tool clamping mechanisms
Installation guidelines:
Mount using M10x1.5 mounting bolts (max torque 35N·m). Maintain ≥20mm clearance
around valve for heat dissipation. Lubricate with ISO VG32 hydraulic oil.
For vertical mounting, install exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | SAUF100X125S-10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
