Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-08B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X150-08B Valve-Integrated Cylinder Specifications
- Model: SAUF100X150-08B
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Medium temperature: -20℃ to 80℃ (non-freeze conditions)
- Port size: Rc1/4 (G1/4 optional)
- Voltage options: DC24V (±10%), AC110V/220V (50/60Hz)
- Valve type: Double coil latching (auto-hold function)
- Mounting style: ISO 15552 standard accessory compatibility
- Cushioning: Adjustable pneumatic cushion (both ends)
- Body material: Aluminum alloy (anodized) with stainless steel rod
- Seal material: NBR (Nitrile rubber)
- Weight: 3.5kg (excluding accessories)
- Dimensions: 310mm(L) × 100mm(W) × 112mm(H) (full extension)
- Response time: ≤50ms (valve switching at rated voltage)
- Protection rating: IP67 (dust/water resistant)
Space-saving combination unit integrating a ISO-standard cylinder and directional control valve, featuring low friction design with ≤0.15 dynamic friction coefficient. Includes magnetic piston for position sensing compatibility. Requires 5μm filtered dry air (lubricated or non-lubricated).
- High-cycle automation: 500,000+ cycles rated
- Plastic injection molding machine ejectors
- Automotive assembly line clamping devices
- Food processing conveyor gate controls
- High-temperature press systems (with air cooling)
Installation note:
Mount valve section upward to prevent debris accumulation. Allow ≥20mm clearance around cylinder for heat dissipation. Use M5x0.8 mounting screws with 12N·m torque limit.
| Property | Property Value |
|---|---|
| sku | SAUF100X150-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
