Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X150-10A Valve-in-Cylinder Specifications
- Model: SAUF100X150-10A
- Type: ISO 15552 compliant cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm (3.94")
- Stroke: 150mm (5.91")
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: G3/8 (NPT1/2 optional)
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Weight: 6.8kg (14.99 lbs) with valve assembly
- Dimensions: 328mm(L) × 122mm(W) × 122mm(H)
- Piston rod thread: M20×1.5
- Cushioning: Adjustable pneumatic cushion
- Seal material: Polyurethane (NBR optional)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Protection rating: IP67 (valve), IP40 (cylinder)
- Cycle rate: ≤5 Hz
- Lubrication: Pre-lubricated (ISO VG32 recommended)
This integrated valve-cylinder unit combines a heavy-duty ISO cylinder with direct-mounted solenoid valve, eliminating piping requirements. Features corrosion-resistant anodized aluminum construction with chrome-plated piston rod. The 10A suffix indicates 1/4" NPT pilot exhaust with built-in silencer. Requires 5μm filtered air with 30-50% relative humidity.
- Plastic injection molding machine ejectors
- Automotive welding fixture clamping
- Palletizing robot end-effector actuators
- Paper converting equipment
- Die-casting machine core pulls
Installation guidelines:
Mount using 12.9 grade M10×1.5 mounting bolts (torque 47-52 N·m).
Maintain minimum 30mm clearance around valve exhaust ports.
Lubricate through air supply (ISO VG32 oil mist at 1:3000 ratio).
| Property | Property Value |
|---|---|
| sku | SAUF100X150-10A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
