Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 150mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke150 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A
The SAUF100X150-10A is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The extruded aluminum barrel is shorter than an ISO 15552 unit of the same bore. This 100mm bore uses a 1/2" cylinder port and generates 3927N push force at 0.5MPa.
The integrated valve has a 3/8" port, Cv 1.68 flow, and cycles up to 4 times per second. The AC220V terminal entry coil is IP65 rated with a 0.05s response. Size force within the 0.15-0.8MPa valve window, not the 1.0MPa cylinder body rating. Based on the 0.5MPa push figure, the safe working load is roughly 2356N, yielding a 200kg vertical lift capacity with a 2:1 margin.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×150 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A Is Used
Heavy Press Stand
Decentralized pressing station using one coil signal to drive the 100mm bore, avoiding long tubing runs from a central manifold.
Pallet Diverter
Independent actuator for a diverter arm where mounting a separate remote valve is impractical, saving manifold space.
Material Lift Gate
Single-signal lifting gate on a packaging line, utilizing the built-in 4M310 valve to simplify machine wiring.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A the Right Choice?
For sizing, the neighboring 80mm bore yields 2513N push at 0.5MPa, while the 100mm bore provides 3927N. Confirm the AC220V terminal entry coil and PT threads suit your control system. The rod retracts when energized but can be reconfigured to extend by repositioning the valve. Because this SKU lacks the S suffix for a magnet, it cannot accept a magnetic switch. Always operate within the 0.15-0.8MPa valve range. The valve routes air and is not a lock; for load holding on air loss, add an external rod lock or pilot-operated check valve. For this 150mm stroke, ensure adequate side-load guidance.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10A FAQ
It delivers 3927N push and 3681N pull at 0.5MPa, reaching 6282N push at 0.8MPa. The built-in valve is a 4M310-10 with a 3/8" port and Cv 1.68. The AC220V coil operates at 0.15-0.8MPa, which is the working limit for the assembled unit.
By default the rod retracts when the coil is energized. You can reconfigure it to extend when energized simply by repositioning the built-in valve. This allows flexible machine sequencing without extra remote valves.
