Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150-10B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X150-10B Valve-Equipped Cylinder Specifications
- Model: SAUF100X150-10B
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Port size: G3/8 (NPT1/2 optional)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Cushioning: Adjustable air cushion at both ends
- Weight: 3.8kg (including valve assembly)
- Dimensions: 310mm(L) × 122mm(W) × 122mm(H)
- Protection rating: IP67 (dust/water resistant)
- Response time: ≤50ms (valve switching)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km)
Integrated pneumatic solution combining a high-torque cylinder with direct-mounted directional control valve. Features low-friction piston seals and anti-rotation rod design. The aluminum alloy body with hard anodized coating ensures corrosion resistance in humid environments. Includes magnetic piston for position sensing compatibility.
- Automated material handling systems
- Plastic injection molding ejectors
- Textile machinery clamping mechanisms
- Automotive assembly line tooling
- Food processing vertical lift systems
Installation note:
Maintain 15mm minimum clearance around valve section for heat dissipation.
Use M6 mounting screws (not included) with 12Nm torque limit.
For vertical installations, install valve facing downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | SAUF100X150-10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
