Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150S-08A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X150S-08A Valve-Integrated Cylinder Specifications
- Model: SAUF100X150S-08A
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8 (BSPP thread)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max air consumption: 4.5 L/min (at 0.5MPa)
- Seal material: Heat-resistant NBR (Nitrile) up to 90℃
- Temperature range: -20℃ to 80℃ (non-freezing)
- Response time: ≤50ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Weight: 3.65kg (excluding accessories)
- Dimensions: 340mm(L) × 128mm(W) × 128mm(H) (fully retracted)
High-torque integrated cylinder-valve unit featuring dual piston seals and magnetic position sensing capability. The aluminum alloy body with hard anodized coating provides corrosion resistance in humid environments. Includes built-in silencer (35dB reduction) and manual override button for emergency operation. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Press machine ejection systems (metal stamping)
- Automated palletizing robot end-effectors
- Plastic injection molding machine core-pulling
- Heavy-duty conveyor gate control
- Textile machinery tensioning mechanisms
Installation guidelines:
Mount using M8x1.25 mounting bolts (ISO 14839-1) with 22-25Nm torque.
Maintain 50mm clearance around valve section for heat dissipation.
Lubricate with ISO VG32 turbine oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SAUF100X150S-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
