Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X150S-08B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Valve-Integrated Cylinder SAUF100X150S-08B Specifications
- Model: SAUF100X150S-08B
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 150mm (±5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Medium temperature: -10℃ to 70℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Valve type: Pilot-operated with manual override
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Port size: 1/4" NPT (G1/8 optional)
- Protection rating: IP67 (valve section), IP40 (cylinder)
- Material: Aluminum alloy body, NBR seals, CRMO steel piston rod
- Weight: 3.8kg (excluding accessories)
- Dimensions: 300mm(L) × 118mm(W) × 118mm(H) (fully retracted)
- Response time: ≤100ms (valve switching)
- Air consumption: 50NL/min (at 0.5MPa)
Integrated valve-cylinder unit combining compact design with high thrust capacity (up to 706N at 0.7MPa). Features anti-rotation mechanism and multiple mounting options (front flange, rear pivot). Built-in silencers reduce exhaust noise to ≤70dB. Suitable for ISO 8573-1:2010 [3:4:3] class compressed air.
- High-speed clamping systems in injection molding
- Palletizing robot end-effector actuation
- Automated conveyor gate control
- Die-casting machine core pulling mechanisms
- Bottle capping station vertical actuators
Installation notes:
Maintain 20mm clearance around valve exhaust ports. Use M5x0.8 mounting screws with 4.4-7.5Nm torque.
Lubricate piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500k operations/year).
| Property | Property Value |
|---|---|
| sku | SAUF100X150S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
