Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X10-10
$107.23
Regular price
$114.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X10-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Adjustment procedure:
Rotate the stroke adjustment screw clockwise to decrease stroke (max 2 full turns).
Always depressurize before adjustment and lock with hex nut after setting.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X10-10 Adjustable Cylinder Technical Details
- Full model designation: SAUJ80X10-10
- Series: SAU-J (Compact adjustable type)
- Bore size: Ø80mm ±0.1mm
- Stroke: 10mm (Adjustable via built-in stroke limiter)
- Operating pressure range: 0.05-1.0 MPa
- Medium temperature: -20℃ to 80℃ (Dry air required)
- Cushioning type: Rubber buffer + adjustable needle valve
- Mounting type: Basic MF1 (Standard foot mounting)
- Port size: G3/8 (BSPP thread)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel (Cr-Mo)
- Seal type: HNBR seals (High nitrile for oil resistance)
- Weight: 2.8kg ±3% (Without accessories)
- Dimensions:
- Body length: 200mm (Min. compacted length)
- Stroke extension: +10mm (Total max length 210mm)
- Width across mounting holes: 100mm
- Height with rod: 145mm (From base to rod end)
- Repeat positioning accuracy: ±0.5mm
- Max theoretical thrust: 502N @0.5MPa
Precision-adjustable compact cylinder featuring dual-position locking mechanism for mid-stroke stopping. Equipped with anti-rotation guide and dust-resistant wiper seal. The T-slot mounting surface allows flexible accessory attachment. Requires 5-40μm filtered compressed air with ISO VG32 lubricant recommended.
Industrial Applications:
- Precision press-fit operations in electronics assembly
- Variable height positioning in CNC tool changers
- Pressure-sensitive clamping systems
- Packaging machine flap adjustment mechanisms
- Automated welding jig positioners
Adjustment procedure:
Rotate the stroke adjustment screw clockwise to decrease stroke (max 2 full turns).
Always depressurize before adjustment and lock with hex nut after setting.
Lubrication: Initial lubrication included. Relubricate every 500km of cumulative travel
using AirTAC PG-1 pneumatic grease. Avoid silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | SAUJ80X10-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <10mm> |
