Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40
$119.80
Regular price
$127.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Installation tip:
For optimal performance, align adjustment screws perpendicular to the cylinder axis and lubricate with ISO VG32 hydraulic oil before initial use. Allow 15mm clearance around adjustment mechanism for tool access.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X100-40 Adjustable Cylinder Specifications
- Model: SAUJ80X100-40
- Type: Double-acting adjustable stroke cylinder with locking mechanism
- Bore size: 80mm
- Stroke: 100mm (±5mm adjustable range)
- Adjustment method: External screw-type stopper with locknut
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Basic type (MF1 footprint)
- Port size: PT1/4 (G1/4 optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: Approximately 2.8kg (excluding accessories)
- Dimensions: 235mm (L) × 98mm (W) × 98mm (H) (at mid-stroke position)
- Rod end thread: M16×1.5
- Max theoretical force: 452N at 0.7MPa (push/pull)
- ISO standard: 15552 compliant
Precision-adjustable pneumatic cylinder featuring a unique dual-locking stopper system that maintains position stability under vibration. The SAUJ series combines 3-stage anodized corrosion resistance with precision ground rod surfaces (Ra0.4μm) for smooth operation. Includes built-in magnetic sensor slots (model suffix "-M" for sensor-ready versions).
Typical Applications:
- Precision press-fit operations in automotive assembly
- Adjustable clamping fixtures for CNC machining centers
- Variable stroke material feeding systems
- Printing machinery with position-sensitive tooling
- Packaging line product height adjustment mechanisms
Installation tip:
For optimal performance, align adjustment screws perpendicular to the cylinder axis and lubricate with ISO VG32 hydraulic oil before initial use. Allow 15mm clearance around adjustment mechanism for tool access.
Adjustment Procedure:
- Loosen locknut using 17mm wrench
- Rotate stopper screw (2.5mm/revolution)
- Test stroke with 0.3MPa air pressure
- Re-tighten locknut while holding screw position
| Property | Property Value |
|---|---|
| sku | SAUJ80X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
