Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S
The AirTAC Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S is a genuine double-acting profile-type standard air cylinder with a Ø80mm bore and 100mm stroke, 3/8" air ports and adjustable end cushioning. Its hard-anodized aluminum-profile barrel is shorter than an ISO 15552 cylinder of the same bore, and it shares SC-series mounting accessories.
- BoreØ80 mm
- Stroke100 mm
- Port size3/8"
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S
The AirTAC SAUJ80X100-40S is a double-acting single-rod profile cylinder with an on-site extend stroke adjustment window of 40 mm. You can trim the nominal 100 mm stroke down to 60 mm using the external stop screw. The extruded aluminum barrel makes it shorter than an ISO 15552 cylinder of the same bore. It features a 3/8 inch port, an M20x1.5 rod thread, and 28 mm adjustable air cushions.
This 80 mm bore delivers a push force of 2513 N and pull of 2268 N at 0.5 MPa. A safe working load is roughly 1508 N, allowing a vertical lift of about 128 kg with a 2:1 margin. The -S suffix means a built-in magnet is present for CMSG, DMSG, or EMSG sensors. Choose Viton H seals to raise the operating temperature from 70 C up to 150 C.
Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S Technical Specifications
| Model | Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S |
|---|---|
| Series | SAU profile-type cylinder |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 3/8" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAU series datasheet. Confirm against the product label before installation. Thread options: PT (blank) / G (BSPP). A high-temperature seal (0-150 °C) is available.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S
| SAU | Profile-type standard cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAU-family variants: SAUD (double rod), SAUJ (adjustable stroke), SAUF (with built-in solenoid valve), and SAU-S with built-in magnet. Seals: TPU (blank) / Viton H / NBR N. Sensor switches: CMSG / DMSG / EMSG.
Where the Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S Is Used
Press Fit Stations
Needs field stroke tuning to accommodate varying bearing thicknesses without reordering cylinders.
Variable Length Diverters
Requires on-site extend adjustment to alter package routing distances on the fly.
Carton Sealing Heads
Demands precise end-position trimming for different box heights using the stop screw.
Is the Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S the Right Cylinder?
When sizing this cylinder, look at both neighbors: the 63 mm bore yields 1559 N push at 0.5 MPa, while the 100 mm bore offers 3927 N. Pick the SAUJ80X100-40S when you need the 2513 N push force but your machine design requires field tuning of the extend position within a 40 mm window. This adjustable stop screw prevents the cost and delay of ordering a custom fixed-stroke SAU cylinder. Mounting options include Basic, FA flange, and LB foot, compatible with the AirTAC SC series. The -S magnet allows electronic or reed sensing. Since the 100 mm stroke is short, side-load guides are less critical, but always guide the load externally for rigid stability.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB — same as SC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-40S FAQ
At 0.5 MPa it pushes 2513 N and pulls 2268 N. Push is 3518 N at 0.7 MPa, 4523 N at 0.9 MPa, and 513 kgf max at 1.0 MPa. The 3/8 inch ported bore has a nominal 100 mm stroke. The external stop screw allows you to shorten the extend stroke by up to 40 mm on-site, giving a usable range of 60 to 100 mm.
The -S suffix indicates a built-in piston magnet for CMSG, DMSG, or EMSG sensors. A plain cylinder does not hold load on air loss; the piston drifts and the 28 mm cushion only decelerates near the end. The stop screw sets the end position but is not a lock. For a held load use an external rod lock or pilot-operated check valve.
