Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X1000-100
$307.30
Regular price
$314.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X1000-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Installation guidelines:
Use M20×1.5 locknut (included) for rod-end mounting. Lubricate with ISO VG32 hydraulic oil
during initial installation. Adjust stroke limiter with 6mm hex key while maintaining 0.3MPa
air pressure during calibration.
Critical note:
Maximum side load capacity 350N. For vertical installations exceeding 45° angle,
mandatory use of guide mechanisms required. Do not exceed 2,500mm/s piston speed.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80 Adjustable Stroke Cylinder SAUJ80X1000-100 Technical Details
- Model Code: SAUJ80X1000-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø80 mm
- Stroke length: 1000 mm (maximum)
- Adjustment range: 0-100 mm (mechanical stroke limiter)
- Operating pressure: 0.1-0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (ISO standard)
- Piston rod thread: M20×1.5
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (nitrile rubber)
- Body material: Aluminum alloy (anodized)
- Weight: 12.8 kg ±2%
- Dimensions (L×W×H):
- Extended length: 1345 mm
- Retracted length: 345 mm
- Mounting face width: 95 mm
- Height with bracket: 128 mm
High-precision industrial cylinder featuring a unique mechanical stroke adjustment mechanism with ±0.5mm repeatability. The dual chrome-plated piston rod (hardness HRC45-50) ensures wear resistance in high-cycle applications. Integrated magnetic sensor slots (T-slot design) enable position feedback installation.
Industrial Applications:
- Variable height positioning in automotive assembly jigs
- Palletizing robot end-effector force control
- Paper processing machinery with dynamic stroke requirements
- Die casting machine ejection systems
- Plastic injection molding machine core-pull mechanisms
Installation guidelines:
Use M20×1.5 locknut (included) for rod-end mounting. Lubricate with ISO VG32 hydraulic oil
during initial installation. Adjust stroke limiter with 6mm hex key while maintaining 0.3MPa
air pressure during calibration.
Critical note:
Maximum side load capacity 350N. For vertical installations exceeding 45° angle,
mandatory use of guide mechanisms required. Do not exceed 2,500mm/s piston speed.
| Property | Property Value |
|---|---|
| sku | SAUJ80X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
