Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000
The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 is a genuine double-acting standard air cylinder with a Ø200mm bore and 1000mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke1000 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000
The SC200X1000 is a robust double-acting pneumatic cylinder delivering 15708 N of push force at 0.5 MPa and up to 28274 N at the maximum operating pressure of 0.9 MPa. Its 200 mm bore and 1000 mm stroke make it a powerful linear actuator for heavy industrial tasks, featuring a 40 mm diameter piston rod and a 33 mm adjustable air cushion for smooth end-of-stroke deceleration.
This tie-rod cylinder has a compact body length of 244 mm (A dimension), resulting in a total extended length of approximately 1244 mm. It operates on filtered air within a pressure range of 0.15-1.0 MPa and a standard temperature range of -20 to +70 °C, using PT3/4 ports for straightforward pneumatic connections.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 Is Used
Heavy Press & Clamping
Generates up to 28274 N of force at 0.9 MPa for powerful pressing, stamping, and clamping operations in metal fabrication and assembly lines.
Material Handling & Lifting
The 1000 mm stroke and high thrust capacity are ideal for lifting heavy loads, operating large diverters, or positioning pallets in bulk material handling systems.
Industrial Automation
Provides reliable, high-force linear actuation for large-scale automation machinery, such as wood processing, textile equipment, and heavy-duty test rigs.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 the Right Cylinder?
Select the SC200X1000 when your application demands high thrust in the 15-28 kN range. For a step down in force, the SC160 bore provides 10053 N of push at 0.5 MPa in a slightly smaller package. For even greater power, the SC250 bore delivers 24544 N at the same pressure. At this 1000 mm stroke, the long, unsupported 40 mm rod is susceptible to bending under side loads; always use an external guide or a guided cylinder configuration to protect the rod bearings and ensure linear motion.
To replace an existing unit, match these five points exactly: 200 mm bore, 1000 mm stroke, PT port thread, basic (no bracket) mounting, and the absence of a magnet. This model is a standard AirTAC SC tie-rod cylinder and is not dimensionally interchangeable with ISO 15552 profile cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000 FAQ
At 0.5 MPa, the push force is 15708 N and the pull force is 15080 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 28274 N. The theoretical maximum force at 1.0 MPa is 3204 kgf.
No. The SC200X1000 is a double-acting cylinder and will not hold its position if air pressure is lost or the directional valve is centered. The piston will drift or the load will drop. For load-holding applications, you must add a pilot-operated check valve or an external mechanical rod brake.
