Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S
The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S is a genuine double-acting standard air cylinder with a Ø200mm bore and 1000mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke1000 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S
The SC200X1000S is a heavy-duty double-acting tie-rod cylinder delivering 15708 N of push force at 0.5 MPa and up to 28274 N at the maximum operating pressure of 0.9 MPa. Its 200 mm bore and 40 mm piston rod drive a 1000 mm stroke, making it a powerful linear actuator for large-scale industrial automation.
This model includes the -S suffix for a built-in magnet, allowing CMSG, DMSG, or EMSG sensors to be clamped directly onto the barrel for reliable, non-contact position sensing. The body length A is 244 mm, the port is PT1/2, and the adjustable air cushion (33 mm) decelerates the rod smoothly at end-of-stroke. Operating temperature range is -20 to +70 °C with the standard TPU seals.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S Is Used
Sawmill Log Handling
Pushes and positions large logs onto the carriage with 15708 N of force at 0.5 MPa. The 1000 mm stroke covers the full width of heavy timber processing lines.
Shipyard Plate Forming
Actuates clamping beams in a hydraulic-style press replacement, using 28274 N at 0.9 MPa to hold steel plates during rolling or bending operations.
Scrap Metal Baler
Drives the compaction ram in a two-stage baler. The built-in magnet provides end-of-stroke confirmation to the PLC before the next cycle begins.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S the Right Cylinder?
Select the SC200 bore when your application requires push forces in the 15708-28274 N range at standard shop air. If your load is closer to 10053 N, stepping down to the SC160 bore can reduce air consumption and cost. For any 1000 mm stroke, especially with a 40 mm rod, external guides or a guided cylinder configuration are strongly recommended to protect the rod bearing from bending moments caused by side loads.
To match an existing cylinder, verify five points: 200 mm bore, 1000 mm stroke, PT1/2 port thread, the built-in magnet for sensor mounting, and the basic (no bracket) mounting style. This is a non-ISO tie-rod cylinder; it is dimensionally shorter than an ISO 15552 profile and is a direct replacement only for another AirTAC SC200 cylinder with the same specifications.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000S FAQ
At 0.7 MPa operating pressure, the theoretical push force is 21991 N. The pull force on the retract stroke is 15080 N at the same pressure, accounting for the 40 mm rod diameter.
Yes. The -S suffix in the model code SC200X1000S indicates a built-in magnet is installed on the piston. This allows you to clamp compatible AirTAC CMSG (reed) or DMSG/EMSG (solid-state) sensors onto the tie-rod barrel to detect piston position without any additional brackets.
