Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH
The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH is a genuine double-acting standard air cylinder with a Ø200mm bore and 1000mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke1000 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH
The AirTAC SC200X1000SH is a large-bore, double-acting pneumatic cylinder delivering a substantial 15708 N of push force at just 0.5 MPa, scaling to 28274 N at the maximum operating pressure of 0.9 MPa. With a 40 mm diameter piston rod and a 33 mm adjustable air cushion, it is engineered to manage high-inertia loads smoothly at the end of its 1000 mm stroke.
This model is configured with a built-in magnet (-S) for direct mounting of CMSG/DMSG/EMSG sensors, and Viton (FKM) seals (-H) that extend the operating temperature range to 0-150°C, making it suitable for hot or aggressive environments. The body length A is 244 mm, resulting in a total extended length of approximately 1244 mm, and it uses a PT3/4 port with an M36x2 rod thread.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH Is Used
Heavy Press & Forming
Provides the high clamping and pressing forces needed in hydraulic-free thermoforming, stamping, and composite molding operations, with Viton seals for hot platen environments.
Foundry & Steel Mill Actuation
Operates reliably in high-temperature ambient conditions up to 150°C for mold handling, gate actuation, and material transfer in foundries and steel processing lines.
Large-Scale Material Handling
Drives heavy-duty lift tables, tilt mechanisms, and conveyor diverters for pallets and bulk materials, with sensor feedback for precise end-of-stroke confirmation.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH the Right Cylinder?
Select the SC200 for applications requiring forces between 15708 N and 28274 N. If your load demands exceed 18095 N at 0.9 MPa, stepping up to the SC250 (24544 N at 0.5 MPa) provides a significant force margin. For a more compact solution with lower force, the SC160 offers 10053 N at 0.5 MPa.
For this 1000 mm stroke, careful side-load management is critical. The long, unsupported 40 mm rod is susceptible to bending under lateral forces. Always use an external guide system or a self-guided rod assembly to prevent rod bearing damage and ensure seal longevity. For replacement, match the 200 mm bore, 1000 mm stroke, PT3/4 port, built-in magnet, and Viton seal material to an identical AirTAC SC model.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1000SH FAQ
At the standard 0.5 MPa operating pressure, the push force is 15708 N and the pull force is 15080 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 28274 N. The theoretical maximum force at 1.0 MPa is 3204 kgf.
No. The SC200 is a double-acting cylinder that requires continuous air pressure to maintain its position. If pressure is exhausted or lost, the piston will drift or drop. For load-holding applications, you must integrate a pilot-operated check valve, a mechanical rod lock, or an external brake.
