Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC
The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC is a genuine double-acting standard air cylinder with a Ø200mm bore and 100mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke100 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC
The AirTAC SC200X100STC is a heavy-duty double-acting tie-rod cylinder delivering a powerful 15708 N push force at 0.5 MPa (28274 N at 0.9 MPa). Its 40 mm diameter piston rod and 244 mm body length A provide a robust platform for demanding linear motion tasks. This model includes a built-in magnet (-S) for direct mounting of CMSG/DMSG/EMSG sensors, and the TC centre trunnion mount with TCM1 bracket for pivoting applications.
With a 100 mm stroke, this cylinder is optimized for short, high-force clamping, pressing, and lifting operations. The adjustable pneumatic cushion (33 mm) decelerates the large mass smoothly at end-of-stroke, protecting the end caps. As a genuine AirTAC component, it ensures reliable performance in industrial automation systems requiring substantial thrust.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC Is Used
Heavy-Duty Clamping
The 15708 N force at 0.5 MPa securely clamps large weldments, engine blocks, or structural assemblies during machining or fabrication, with sensor confirmation via the built-in magnet.
Pallet Lift & Transfer
Provides the high thrust needed to elevate heavy pallets or transfer loads in material handling systems. The TC trunnion mount allows the cylinder to pivot, accommodating the lifting arc.
Press-Fit Assembly
Delivers up to 28274 N of force at 0.9 MPa for pressing bearings, bushings, or pins into heavy housings. Adjustable cushioning protects parts from impact damage during high-speed cycles.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC the Right Cylinder?
Select the SC200 bore when your application requires between 15708 N and 28274 N of force at standard plant pressures. If your load is lighter, stepping down to a 160 mm bore (10053 N at 0.5 MPa) can reduce air consumption and cost. For replacement, match five key points: 200 mm bore, 100 mm stroke, PT port thread, TC centre trunnion mount (F-SC200TC), and the built-in magnet for sensor compatibility. The SC series is a tie-rod design, not an ISO 15552 profile, so dimensional interchangeability is limited to other SC200 tie-rod cylinders.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100STC FAQ
At 0.5 MPa, push force is 15708 N and pull force is 15080 N. At the maximum operating pressure of 0.9 MPa, push force reaches 28274 N. The theoretical maximum at 1.0 MPa is 3204 kgf.
No. The AirTAC SC series is a tie-rod cylinder and is physically shorter than an ISO 15552 profile cylinder. It is not dimensionally interchangeable. It must be replaced with another AirTAC SC200 tie-rod cylinder matching the stroke, port thread, and TC trunnion mount.
