Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC
The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC is a genuine double-acting standard air cylinder with a Ø200mm bore and 100mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke100 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC
The SC200X100TC is a large-bore double-acting pneumatic cylinder delivering 15708 N of push force at 0.5 MPa (28274 N at 0.9 MPa), built for heavy-duty linear actuation. With a 40 mm diameter piston rod and an M36x2 knuckle thread, it handles substantial thrust loads while the 33 mm adjustable air cushion decelerates the piston smoothly at end-of-stroke.
This model is configured with a TC centre trunnion mount, supplied with the TCM1 bracket (F-SC200TC), allowing the cylinder to pivot as the load moves through an arc. The body length A is 244 mm, giving a compact extended length of 344 mm for this 100 mm stroke. PT3/4 port threads and TPU seals suit standard compressed air systems operating from -20 to +70 °C.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC Is Used
Heavy Press & Clamping
Generates up to 28274 N at 0.9 MPa for powerful pressing, stamping, or holding operations on large workpieces in metal fabrication cells.
Pivoting Conveyor Gates
The TC centre trunnion mount allows the cylinder to swing freely, ideal for actuating heavy diverter gates or chutes on aggregate and mining conveyors.
Agricultural Implement Control
Provides the high force needed to raise, lower, or angle heavy implements on towed farm machinery, with the trunnion absorbing frame flex.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC the Right Cylinder?
Choose the SC200X100TC when your application needs a 200 mm bore force class with a pivoting mount. The centre trunnion lets the cylinder swing, eliminating bending stress on the rod from misaligned linear guides. For a fixed linear mount, consider the same bore with LB foot or FA/FB flange options instead.
This cylinder matches replacements that share five key points: 200 mm bore, 100 mm stroke, PT3/4 port thread, TC centre trunnion mounting, and no magnet. Always verify the pivot pin diameter and trunnion position against the existing setup. If your load creates significant side forces, pair this cylinder with an external guide rail system to protect the 40 mm rod and bearing from premature wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X100TC FAQ
At the standard 0.5 MPa operating pressure, it produces 15708 N pushing and 15080 N pulling. At 0.7 MPa, push force is 21991 N, and at the maximum 0.9 MPa, it reaches 28274 N. The theoretical maximum at 1.0 MPa is 3204 kgf.
The TC mount includes a trunnion bracket (TCM1) that clamps around the cylinder body at a specific point, creating a pivot axis. This allows the entire cylinder to swing as it strokes, which is essential when the driven load moves in an arc rather than a straight line. The F-SC200TC accessory kit is included.
