The AirTAC Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S is a genuine double-acting standard air cylinder with a Ø200mm bore and 1010mm stroke, PT3/4 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ200 mm
- Stroke1010 mm
- Port sizePT3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 33 mm
About the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S
The AirTAC SC200X1010S is a double-acting tie-rod cylinder engineered for heavy linear force applications requiring a long, non-standard stroke. With a 200 mm bore and 1010 mm stroke, this model generates a substantial 15708 N of push force at 0.5 MPa (28274 N at 0.9 MPa), making it suitable for large-scale pressing, clamping, and material handling tasks.
This cylinder features a robust 40 mm diameter piston rod with M36x2 threads and PT1/2 ports. The body length A is 244 mm, and the adjustable pneumatic cushion is 33 mm at each end to decelerate high inertial loads. The integrated -S magnet allows direct mounting of CMSG/DMSG/EMSG sensors for reliable end-of-stroke position feedback.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S Technical Specifications
| Model | Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S |
|---|---|
| Series | SC big-bore tie-rod cylinder (ISO 6430 class) |
| Bore size | Ø200 mm |
| Stroke | 1010 mm |
| Acting type | Double acting |
| Port size | PT3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 33 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (approx.) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S
| SC | Standard tie-rod cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1010 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S Is Used
Heavy Pallet Transfer
Pushes loaded pallets across roller conveyors in distribution centers, using its 15708 N force at 0.5 MPa to move multi-ton loads smoothly.
Large Press Tool Actuation
Drives the main ram of a hydraulic-style pneumatic press for forming or stamping, leveraging 28274 N of force at 0.9 MPa for deep-draw operations.
Wood Processing Clamp
Secures large timber beams or engineered lumber during automated sawing and routing, with the long 1010 mm stroke accommodating varied material widths.
Is the Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S the Right Cylinder?
For applications needing less force, the SC160 bore provides 10053 N at 0.5 MPa, while the SC250 bore steps up to 24544 N. With a 1010 mm stroke, this non-standard cylinder requires careful management of side loads and rod deflection. For strokes exceeding 300 mm, always use an external guide or a guided cylinder to protect the rod bearing from bending moments, ensuring long seal life and consistent operation. When replacing, match bore, stroke, PT port thread, basic mount, and the -S magnet option precisely.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC200-250 Tie-Rod Cylinder Aluminum Alloy SC200X1010S FAQ
At 0.5 MPa (5 bar), the push force is 15708 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 28274 N. The theoretical maximum force at 1.0 MPa is 3204 kgf.
A 1010 mm stroke creates a long moment arm. You must not subject the rod to direct side loads. Install an external linear guide rail system to carry the load and use a floating rod coupler to connect the cylinder, ensuring the rod only transmits push/pull force in a straight line.
