Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X1000S-08B
$143.06
Regular price
$150.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCF32X1000S-08B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SCF Standard Tie-Rod Cylinder with Integrated Valve
1. A derivative series combining standard cylinder and valve configurations, compatible with 4M210 and 4M310 valves. Bore sizes 32/40/50 paired with 4M210 valves; bores 63/80/100 paired with 4M310 valves.
2. Enables 1:1 control logic without requiring additional external control valves.
3. Reduces installation time and space requirements, optimized for decentralized applications in large-scale systems.
4. Supports flexible integration with multiple mounting accessories and simplified installation processes.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SCF
Installation Guidelines:
1. Allow 15mm clearance around cylinder body for heat dissipation
2. Use flexible couplings for stroke >500mm applications
3. Align valve electrical connector upward (±15° tolerance)
4. Initial run-in: Cycle 10x at 0.3MPa before full operation
AirTAC SCF32X1000S-08B Standard Tie-Rod Cylinder with Integrated Valve
- Model Code Breakdown: SCF32-X1000S-08B
- SCF: Standard Cylinder Family
- 32: 32mm bore diameter
- X1000S: 1000mm extended stroke (S=standard precision)
- 08B: 1/8" NPT valve port (B=integrated valve version)
- Structure: Double-acting with magnetic piston (DIN ISO 6432)
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Cushioning: Adjustable air cushion at both ends
- Piston Rod: Hard chrome-plated steel (Cr12MoV), M12x1.75 thread
- Seal Material: High-grade NBR with wear-resistant guide rings
- Valve Specifications:
- Type: 5/2-way solenoid valve (single coil)
- Voltage Options: DC24V (±10%), AC110V/220V (±15% at 50/60Hz)
- Response Time: ≤30ms (at rated voltage)
- Flow Rate: 750 l/min (ANR)
- Ambient Temperature: -20℃ to 80℃ (non-freezing)
- Lubrication: Pre-lubricated (Oil mist lubrication recommended)
- Weight: 8.7 kg ±2% (including valve assembly)
- Dimensions:
- Extended Length: 1298mm (stroke + end caps)
- Retracted Length: 298mm
- Body Diameter: 50mm (outer cylinder)
- Mounting Face: 32x32mm square pattern
- Accessories: Built-in magnet for position sensing (compatible with CS1 series sensors)
Industrial-grade tie-rod cylinder featuring integrated 5/2-way valve for space-optimized automation systems. The anodized aluminum construction ensures corrosion resistance in humid environments, while the triple-seal piston design minimizes internal leakage. Requires 40μm filtered compressed air with ≤1% oil content.
Typical Applications:
- Long-stroke press machines (book binding, metal stamping)
- Automated material handling systems
- Plastic injection molding ejectors
- Textile machinery tension control
- Solar panel production line actuators
Installation Guidelines:1. Allow 15mm clearance around cylinder body for heat dissipation
2. Use flexible couplings for stroke >500mm applications
3. Align valve electrical connector upward (±15° tolerance)
4. Initial run-in: Cycle 10x at 0.3MPa before full operation
| Property | Property Value |
|---|---|
| sku | SCF32X1000S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <1000mm> |
