Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X100S-08B
AirTAC SCF Standard Tie-Rod Cylinder with Valve - SCF32X100S-08B
- Model: SCF32X100S-08B
- Type: ISO 15552 compliant tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 100mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Medium: Clean compressed air (lubricated or non-lubricated)
- Cushioning type: Adjustable rubber buffers at both ends
- Mounting: Basic front flange (ISO 15552 MF1), multiple mounting options via accessory kits
- Port size: G1/8 (EN 10226)
- Voltage: DC24V (standard), AC options available
- Temperature range: -20℃ to 80℃
- Weight: 1.65kg (excluding accessories)
- Dimensions:
- Total length: 202mm (stroke 100 + 102mm base)
- Body diameter: 45mm
- Mounting flange: 80×80mm
- Seal material: High-grade NBR with wear-resistant piston rings
- Protection rating: IP54 (valve section), IP40 (cylinder)
- Response time: ≤50ms (valve switching)
A space-saving pneumatic solution combining cylinder and valve in one unit, featuring enhanced side load capacity through precision-guided piston rods. The integrated valve reduces piping complexity by 70% compared to traditional setups. Special anti-vibration design ensures stable operation at speeds up to 1.2m/s. Pre-lubricated for maintenance-free operation up to 3,000km travel distance.
- High-speed pick-and-place systems in electronics assembly
- Clamping mechanisms in CNC machine tools
- Automated packaging line actuators
- Plastic injection molding ejectors
- Automotive welding fixture positioning
Installation note:
Maintain minimum 15mm clearance around valve manifold for heat dissipation.
Use flexible couplings when connecting to rigid structures.
For vertical mounting, install air exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | SCF32X100S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
