Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X120S-08B
AirTAC SCF32X120S-08B Tie-Rod Cylinder with Integrated Valve Specifications
- Model: SCF32X120S-08B
- Type: ISO 15552 standard tie-rod cylinder with built-in 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 120mm (adjustable cushioning)
- Port size: G1/8 (NPT1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Weight: 1.85kg (with valve)
- Dimensions:
- Length: 240mm (full extension)
- Width: 48mm (valve block included)
- Height: 52mm (including mounting brackets)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Air consumption: 14.5L/min @ 0.5MPa
- Response time: ≤50ms (valve switching)
- Protection rating: IP67 (cylinder), IP65 (valve)
High-efficiency combination unit featuring a robust tie-rod cylinder with integrated 5/2-way pilot-operated valve. The compact design reduces piping complexity while maintaining ISO 15552 mounting compatibility. Features dual adjustable cushions and magnetic piston for position sensing capability. Requires ISO 8573-1 class 3 filtered air (40μm, oil content ≤1mg/m³).
- Automated material handling systems
- Plastic injection molding ejectors
- Food processing conveyor gates
- Automotive assembly clamping devices
- Pharmaceutical packaging actuators
Installation note:
Lubricate through air supply (ISO VG32 recommended) for initial operation.
Maintain minimum 20mm clearance around valve for heat dissipation.
Use shock absorbers when stroke-end impact velocity exceeds 500mm/s.
| Property | Property Value |
|---|---|
| sku | SCF32X120S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
