Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X125S-08B
AirTAC SCF Standard Cylinder Tie-rod Type with Valve SCF32X125S-08B Specifications
- Model: SCF32X125S-08B
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 125mm
- Mounting style: Standard square (ISO 15552 footprint)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (EN standard)
- Valve type: Direct-acting with manual override
- Voltage options: DC12V/24V, AC110V/220V (coil interchangeable)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR (standard), optional FKM
- Protection rating: IP67 (valve section), IP40 (cylinder)
- Weight: 2.45kg (with valve)
- Dimensions:
- Total length (extended): 265mm
- Body diameter: 42mm
- Mounting hole spacing: 25×25mm
- Valve block size: 35mm(W)×55mm(H)×42mm(D)
High-efficiency combination cylinder with integrated directional control valve, designed for space-constrained automation systems. Features dual adjustable air cushions for smooth end-of-stroke deceleration and corrosion-resistant construction. The modular valve assembly allows quick field replacement without dismounting the cylinder.
- Robotic material handling systems
- Packaging machine clamping mechanisms
- Automotive assembly line tooling
- Food processing equipment (with optional FKM seals)
- Plastic injection molding ejectors
Installation note:
Maintain minimum 30mm clearance around valve for heat dissipation.
Use flexible tubing between valve and cylinder to prevent alignment stress.
Lubricate through port lubricators (MQL compatible).
- Max piston speed: 500mm/s (cushioned)
- Response time: ≤15ms (valve switching)
- Air consumption: 1.45L/stroke @0.5MPa
- Service life: 5,000km (rod travel distance)
| Property | Property Value |
|---|---|
| sku | SCF32X125S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
