Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X130S-08B
$91.16
Regular price
$98.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCF32X130S-08B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SCF Standard Tie-Rod Cylinder with Integrated Valve
1. A derivative series combining standard cylinder and valve configurations, compatible with 4M210 and 4M310 valves. Bore sizes 32/40/50 paired with 4M210 valves; bores 63/80/100 paired with 4M310 valves.
2. Enables 1:1 control logic without requiring additional external control valves.
3. Reduces installation time and space requirements, optimized for decentralized applications in large-scale systems.
4. Supports flexible integration with multiple mounting accessories and simplified installation processes.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SCF
Installation Best Practices:
Mount using front flange (NF32) or rear pivot (MP4) options. Maintain 0.5-1mm alignment tolerance during installation. For vertical mounting, install valve exhaust ports downward to prevent condensation accumulation. Recommended maintenance: Relubricate every 500km stroke distance.
AirTAC SCF32X130S-08B Tie-Rod Cylinder with Valve Specifications
- Model Code Breakdown: SCF(Standard Cylinder) 32(Bore Ø32mm) X130(Stroke 130mm) S(Tie-Rod) -08B(Valve Integrated)
- Bore Size: 32mm (ISO 6432 standard)
- Stroke: 130mm ±1mm tolerance
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Max Thrust: 226N at 0.63MPa (Piston area 35.8cm²)
- Cushioning: Adjustable air cushion at both ends
- Port Size: G1/8 (ISO 1179-1)
- Valve Type: 5/2-way single solenoid (24VDC/AC110V/AC220V optional)
- Response Time: ≤50ms (valve switching)
- Seal Material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature Range: -20℃ to 120℃ (dry air required above 80℃)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Protection Rating: IP67 (Dust/water resistant)
- Weight: 1.85kg ±3% (including valve and mounting accessories)
- Dimensions:
- Length: 276mm (Full extended length)
- Width: 48mm (Body diameter with mounting brackets)
- Height: 48mm (Square body profile)
High-precision tie-rod cylinder with integrated 5/2-way solenoid valve, featuring dual-action piston with magnetic position sensing capability. The chrome-plated piston rod (hardness HRC 45-55) ensures wear resistance in high-cycle applications. Optional auto-switch mounting slots (M5) for position feedback devices.
Industrial Applications:
- High-speed pick-and-place systems in electronics assembly
- Clamping fixtures for CNC machining centers
- Packaging line diverters with <1s cycle times
- Cleanroom-compatible automation (when using oil-free air)
- Plastic injection molding ejector systems
Installation Best Practices:
Mount using front flange (NF32) or rear pivot (MP4) options. Maintain 0.5-1mm alignment tolerance during installation. For vertical mounting, install valve exhaust ports downward to prevent condensation accumulation. Recommended maintenance: Relubricate every 500km stroke distance.
| Property | Property Value |
|---|---|
| sku | SCF32X130S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 130mm |
