Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X150S-08B
AirTAC SCF Standard Cylinder Tie-Rod Type with Valve SCF32X150S-08B Specifications
- Model: SCF32X150S-08B
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32 mm
- Stroke: 150 mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable air cushion at both ends
- Valve type: Monoblock 5/2-way solenoid valve
- Voltage options: DC24V (±10%), AC110V/220V (50/60Hz)
- Operating temperature: -10℃ to 70℃ (no freeze)
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP67 (valve section IP65)
- Weight: 2.85 kg (including valve)
- Dimensions:
- Length: 250 mm (full retracted)
- Width: 55 mm (including valve block)
- Height: 48 mm (cylinder body)
Heavy-duty industrial cylinder featuring integrated valve mounting for space-saving installations. The hard-anodized aluminum barrel and chrome-plated piston rod ensure corrosion resistance in harsh environments. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 40μm filtered lubricated air (ISO 8573-1).
- Automated assembly line clamping mechanisms
- Plastic injection molding ejector systems
- CNC machine tool positioning devices
- Automotive welding fixture actuators
- Food packaging machinery pushers
Installation note:
Maintain 0.5mm minimum clearance between magnetic piston and sensor. For vertical mounting,
use model with locking nut (add "-L" suffix). Lubricate rod weekly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SCF32X150S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 150mm |
