Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X160S-08B
AirTAC SCF32X160S-08B Rod-Style Standard Cylinder with Integrated Valve
- Model: SCF32X160S-08B
- Type: Double-acting cylinder with built-in 5/2-way solenoid valve
- Bore diameter: 32 mm (±0.1mm tolerance)
- Stroke: 160 mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Temperature range: -10℃ to 80℃ (dry air required below 0℃)
- Cushioning type: Adjustable rubber buffers at both ends
- Port size: 1/8" NPT (G1/8 optional)
- Mounting style: Standard ISO 15552 foot mounting (NF1 pattern)
- Piston rod material: Hard chrome-plated steel (4-6μm coating)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seal material: NBR (Nitrile) standard / Optional FKM (Viton)
- Weight: 1.85 kg (excluding accessories)
- Dimensions: 250mm(L) × 52mm(W) × 52mm(H)
- Voltage options: DC12V/24V, AC110V/220V (50/60Hz)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (valve section)
High-precision industrial cylinder featuring integrated directional control valve for space-constrained automation systems. The through-rod design enables stable linear motion with ±0.5mm repeat positioning accuracy. Optimized air passage design reduces flow resistance by 30% compared to conventional models.
- Pick-and-place robotic end effectors
- Plastic injection molding ejector systems
- Semiconductor wafer handling equipment
- Pharmaceutical blister packaging machines
- Automotive assembly line clamping devices
Installation note:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | SCF32X160S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 160mm |
