Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X175S-08B
AirTAC SCF Standard Cylinder Tie-Rod Type with Valve SCF32X175S-08B Specifications
- Model Code Breakdown: SCF32X175S-08B
- SCF: Standard Cylinder Tie-Rod Series
- 32: Bore size (32mm)
- 175: Stroke length (175mm)
- S: Built-in speed controller
- 08: Valve size (G1/8 port)
- B: Double-acting with magnetic piston
- Bore Diameter: 32mm (±0.1mm tolerance)
- Stroke Tolerance: +2.0mm/-0mm
- Operating Pressure: 0.05-1.0 MPa
- Ambient Temperature: -20℃ to 80℃ (non-freezing)
- Piston Speed: 50-800 mm/s (optimal at 500 mm/s)
- Cushioning: Adjustable elastic cushion at both ends
- Mounting: ISO 15552 standard, multiple mounting options
- Basic: MA1 (front flange)
- Optional: MB1 (rear flange), MP2 (side lug)
- Valve Specifications:
- Type: 5/2-way solenoid valve
- Voltage: DC24V (±10%) / AC110V (50/60Hz)
- Response Time: ≤15ms (at 0.5MPa)
- Power Consumption: 1.2W (DC), 3.5VA (AC)
- Materials:
- Tube: Aluminum alloy (hard anodized)
- Piston Rod: Chrome-plated steel (S45C)
- Seals: NBR (standard), optional FKM
- Weight: 2.8 kg (with valve and accessories)
- Dimensions:
- Length: 283mm (full retraction: 108mm + 175mm stroke)
- Width: 52mm (valve block included)
- Height: 52mm (square profile)
- Protection Rating: IP65 (dust-tight & water jet resistant)
- Lubrication: Pre-lubricated (DOP-free grease), maintenance-free for 2000km travel
A high-precision industrial cylinder with integrated valve for space-constrained automation systems. Features dual adjustable cushions for smooth end-of-stroke deceleration and magnetic piston for position feedback. The aluminum alloy construction ensures corrosion resistance while maintaining structural rigidity. Integrated manifold design reduces potential leak points by 40% compared to separate valve-cylinder setups.
- Plastic injection molding machine ejectors
- Automated assembly line clamping units
- CNC machine tool door interlocks
- Food packaging vertical lift systems
- Semiconductor wafer handling robots
Installation Guidelines:
Mount cylinder horizontally for optimal seal life. Use flexible tubing between valve and cylinder if vibration exceeds 0.5G. Perform 50-100 test cycles at 0.3MPa before full-pressure operation. Magnetic sensor cables must be routed separately from power lines (min. 50mm spacing).
| Property | Property Value |
|---|---|
| sku | SCF32X175S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 175mm |
