Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X250S-08B
AirTAC SCF Standard Tie-Rod Cylinder with Valve - SCF32X250S-08B Specifications
- Model: SCF32X250S-08B
- Type: ISO 15552 compliant tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32mm (±0.1mm manufacturing tolerance)
- Stroke: 250mm (adjustable stroke cushioning)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Port size: G1/8 (ISO 228 standard)
- Cushioning type: Adjustable pneumatic cushion at both ends
- Seal material: NBR (Nitrile) with wear-resistant guide rings
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Mounting type: Basic foot mounting with optional accessories (MF series)
- Built-in valve voltage: DC24V/AC110V/AC220V (specify when ordering)
- Weight: 1.65kg (excluding mounting accessories)
- Dimensions: 50mm(W) × 50mm(H) × 428mm(L) (stroke length included)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Response time: ≤100ms (valve switching at rated voltage)
- Protection rating: IP40 (standard), IP67 optional with protective cover
- Air consumption: 1.23L/stroke at 0.5MPa
High-efficiency combination unit integrating cylinder and valve, designed for space-constrained automation systems. Features dual-action piston with magnetic coupling for position sensing compatibility. The modular design allows quick valve replacement without disassembling cylinder components. Requires ISO 8573-1:2010 Class 3 compressed air.
- Robotic material handling systems
- Plastic injection molding ejectors
- CNC machine tool clamping mechanisms
- Automated assembly line positioning
- Packaging machine pusher mechanisms
Installation note:
Maintain minimum 30mm clearance around valve section for heat dissipation.
Use flexible tubing between valve and cylinder ports to prevent alignment stress.
Lubricate through air supply (ISO VG32 turbine oil recommended).
| Property | Property Value |
|---|---|
| sku | SCF32X250S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <250MM> → <250mm> |
