Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X400S-08B
AirTAC SCF32X400S-08B Standard Tie-Rod Cylinder with Integrated Valve Specifications
- Model: SCF32X400S-08B
- Type: Double-acting tie-rod cylinder with built-in 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 400mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning type: Fixed cushion (adjustable end caps)
- Port size: PT1/8 (G1/8 optional)
- Mounting style: Standard ISO 15552 foot mounting with 32mm center distance
- Valve type: Direct-acting 5/2-way solenoid valve with manual override
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Body material: Aluminum alloy (anodized finish)
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP67 (rod extended), IP65 (valve section)
- Weight: 2.65 kg (5.84 lbs) with valve assembly
- Dimensions: 548mm(L) × 50mm(W) × 50mm(H) (stroke-dependent length)
High-performance combination cylinder-valve unit featuring reduced installation space (30% smaller footprint vs separate components). The integrated design minimizes air leakage points with precision-machined subplate mounting. Enhanced dust/wear resistance through triple-lip rod seal and chrome-plated piston rod (surface hardness HRC 45-50). Includes magnetic piston for position sensing compatibility.
- High-speed pick-and-place systems (cycle rates up to 3Hz)
- Plastic injection molding machine ejectors
- Automated assembly line clamping mechanisms
- Textile machinery tension control systems
- Food processing conveyor gate actuators
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. Use M5x0.8 mounting screws (45mm depth) with 12N·m torque limit.
Lubricate with ISO VG32 hydraulic oil (1-2 drops/min air line lubricator recommended).
Allow 50mm front clearance for rod extension.
| Property | Property Value |
|---|---|
| sku | SCF32X400S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <400mm> |
