Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X450S-08B
AirTAC SCF Standard Tie-Rod Cylinder with Valve – SCF32X450S-08B Technical Details
- Model Code: SCF32X450S-08B
- Series: SCF Standard Cylinder (Tie-Rod Construction)
- Bore Size: 32mm
- Stroke: 450mm (±1mm tolerance)
- Valve Integration: Built-in 5/2-way solenoid valve (24VDC)
- Port Thread: G1/8 (ISO228 standard)
- Operating Pressure: 0.05–1.0 MPa
- Piston Speed: 50–800 mm/s
- Cushioning: Adjustable air cushion (both ends)
- Seal Material: High-grade NBR (Nitrile Butadiene Rubber)
- Ambient Temperature: -20℃ to 80℃ (non-freezing)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Mounting: Basic front/rear flange (optional accessories available)
- Weight: 3.8kg ±2% (including valve assembly)
- Dimensions: 638mm(L) × 50mm(W) × 50mm(H) (stroke extended)
- Rod Thread: M16×1.5 (external)
- Protection Class: IP54 (standard sealing)
Industrial-grade tie-rod cylinder featuring integrated valve for space-optimized pneumatic systems. The double-rod design ensures precise linear motion control with excellent load-bearing capacity. Robust construction with chrome-plated piston rod (Hard Chrome Plating, 20-25μm) resists corrosion in humid environments. Includes magnetic piston for position sensing compatibility.
- Plastic injection molding machine ejectors
- Automated assembly line clamping mechanisms
- Paper processing equipment actuators
- Heavy-duty material handling systems
- Packaging machine vertical lifts
Installation Guidelines:
Maintain 0.5mm minimum clearance between magnetic switch and cylinder body.
Use locknuts (M6) for vibration-prone applications. Lubricate rod every 500km stroke
movement under continuous operation. Avoid side load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SCF32X450S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 450mm |
