Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X500S-08B
AirTAC SCF Standard Tie-Rod Cylinder with Valve (SCF32X500S-08B) Specifications
- Model: SCF32X500S-08B
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 500mm (±1mm tolerance)
- Operation mode: Double acting with auto switch function
- Working pressure: 0.05-1.0 MPa (7-145 psi)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G1/8 (EN standard) with NPT option
- Voltage: DC24V (standard), AC110V/220V optional
- Material: Aluminum alloy cylinder tube, chrome-plated piston rod (Cr-Mo steel)
- Seal material: NBR (Nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (continuous operation)
- Protection rating: IP67 (dust/water resistant)
- Weight: 4.8kg (excluding accessories)
- Dimensions: 650mm(L) × 52mm(W) × 52mm(H) (extended length)
- Retracted length: 150mm (base cylinder body)
- Max piston speed: 500-700 mm/s (lubricated)
High-precision industrial cylinder featuring integrated valve control and precision honed inner bore. The SCF32X500S-08B combines robust construction with a space-saving design, utilizing cold-drawn tubing for smooth operation. The built-in 5/2-way valve enables direct pneumatic control without external piping, with LED status indication for position feedback.
- Automated assembly line clamping mechanisms
- Packaging machinery ejection systems
- Die-casting machine core-pulling operations
- Automotive welding fixture positioning
- Plastic injection molding machine actuators
Installation guidelines:
Mount using M8x1.25 mounting bolts with 35N·m torque limit.
Maintain 0.5-1mm alignment tolerance during installation.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SCF32X500S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 500mm |
