Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X50S-08B
AirTAC SCF32X50S-08B Rod-Style Standard Cylinder with Integrated Valve
- Full model code: SCF32X50S-08B
- Bore size: 32mm (ISO 6432 standard)
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.1-1.0 MPa
- Cushioning type: Adjustable elastic buffer
- Port size: PT1/8 (G1/8 optional)
- Built-in valve type: 5/2-way single solenoid
- Voltage options: DC24V (±10%), AC110V/220V (50/60Hz)
- Ambient temperature: -20℃ to +80℃
- Piston speed: 50-800mm/s
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel (Cr-Mo)
- Seals: NBR (nitrile rubber)
- Protection class: IP65 (dust-tight & water jet resistant)
- Weight: 0.82kg (without accessories)
- Dimensions:
- Extended length: 158mm
- Retracted length: 108mm
- Body width: 45mm (including tie rods)
- Mounting height: 32mm (center axis)
Heavy-duty tie-rod cylinder with integrated 5/2-way solenoid valve, featuring precision honed inner tube and wear-resistant rod seals. The compact valve-on-cylinder design eliminates external piping requirements, with 0.1W low-power coil and surge protection circuitry. Includes magnetic piston for position sensing compatibility.
- Clamping fixtures in CNC machining centers
- Actuation in automated assembly lines
- Packaging machine ejector systems
- Textile machinery thread control
- Semiconductor handling equipment
Installation guidelines:
Mount using SW32 standard bracket (sold separately). Lubricate through built-in grease nipple (ISO VG32 recommended).
Maintain minimum 15mm clearance around valve section for heat dissipation. Use M3x0.5 screws for sensor mounting.
| Property | Property Value |
|---|---|
| sku | SCF32X50S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <50mm> |
