Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X65S-08B
AirTAC SCF32X65S-08B Standard Tie-Rod Cylinder with Valve Specifications
- Model: SCF32X65S-08B
- Type: Double-acting tie-rod cylinder with integrated 3/2-way solenoid valve
- Bore diameter: 32mm (±0.1mm tolerance)
- Stroke: 65mm (adjustable stroke limiter optional)
- Operating pressure: 0.1-0.9 MPa
- Port size: PT1/8 (G1/8 adaptor available)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard foot mounting (ISO 15552 compliant)
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Seal material: Nitrile Butadiene Rubber (NBR) standard (FKM optional)
- Protection rating: IP40 (IP67 with optional protective cover)
- Voltage options: DC12V/24V, AC110V/220V (±10% tolerance)
- Valve type: Normally closed pilot-operated solenoid valve
- Response time: ≤15ms (at 0.5MPa)
- Weight: 0.82kg (excluding accessories)
- Dimensions: 214mm(L) × 50mm(W) × 50mm(H) (full extension)
A high-precision modular cylinder combining compact design with integrated valve control. Features chrome-plated piston rod (HCP hardness ≥700HV) and anodized aluminum barrel for corrosion resistance. The built-in valve reduces external tubing requirements by 60%, ideal for clustered pneumatic systems. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Pick-and-place automation in electronics assembly lines
- Clamping mechanisms for CNC fixture systems
- Actuation of sorting gates in packaging machinery
- Valve control in food processing equipment (food-grade grease option)
- Precision positioning in semiconductor handling systems
Installation notes:
(1) Maintain ≥3mm alignment tolerance during rail mounting.
(2) Lubricate piston rod weekly in high-cycle applications (>500,000 cycles/month).
(3) For vertical mounting, use model suffix "-08BV" with reinforced mounting brackets.
| Property | Property Value |
|---|---|
| sku | SCF32X65S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 65mm |
