Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF32X75S-08B
AirTAC SCF Standard Tie-Rod Cylinder with Valve (SCF32X75S-08B) Specifications
- Model: SCF32X75S-08B
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 32mm
- Stroke: 75mm
- Operating pressure: 0.05–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: PT1/8 (G1/8 optional)
- Valve type: Monostable with manual override
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR (standard), optional FKM
- Protection rating: IP67 (valve), IP54 (cylinder)
- Weight: 1.85kg (with valve)
- Dimensions:
- Length: 210mm (including rod)
- Width: 42mm (cylinder body)
- Height: 42mm (cylinder body)
- Valve block: 55mm(L) × 34mm(W) × 48mm(H)
Robust tie-rod cylinder featuring integrated directional control valve for space-constrained automation systems. The modular design combines ISO 15552 cylinder standards with direct-mounted valve technology, enabling rapid response (≤20ms switching time). Includes magnetic piston for position sensing compatibility and anti-rotation rod for precise actuation.
- Plastic injection molding machine ejectors
- CNC fixture clamping systems
- Automated conveyor gate controls
- Textile machinery tensioning devices
- Food processing packaging lines (with optional FKM seals)
Installation note:
Maintain minimum 15mm clearance around valve for heat dissipation. Use M5x0.8 mounting screws (max torque 2.5N·m).
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SCF32X75S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Standard Voltage | DC24V |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 75mm |
