Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X250-08A
AirTAC SCF Standard Tie-Rod Cylinder with Valve - SCF40X250-08A Specifications
- Model Code: SCF40X250-08A
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore Size: 40mm (ISO 6432 standard)
- Stroke: 250mm (±1.5mm tolerance)
- Operating Pressure: 0.1-1.0 MPa (14.5-145 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting Style: Basic foot mounting (NF1 pattern) with optional accessory brackets
- Port Size: PT1/8 (NPT1/8 optional)
- Temperature Range: -20℃ to 80℃ (using NBR seals)
- Material: Aluminum alloy cylinder tube, hardened stainless steel piston rod
- Seal Type: Multi-lip NBR seals with wear-resistant guide rings
- Voltage Compatibility: DC12V/24V or AC110V/220V (specify when ordering)
- Response Time: ≤100ms (valve switching at rated voltage)
- Weight: 2.8kg ±3% (excluding accessories)
- Dimensions: 450mm(L) × 64mm(W) × 64mm(H) (retracted length)
- Protection Class: IP54 (standard), IP67 available on request
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if maintenance required)
The SCF40X250-08A combines a robust tie-rod cylinder with an integrated directional control valve, reducing piping complexity in compact installations. Its hard-anodized aluminum construction resists corrosion in humid environments, while the chrome-plated piston rod ensures smooth operation across 500km+ service life. The valve's low power design (1.6W typical) features surge protection against voltage spikes.
- High-cycle press machines (200-500 strokes/hour)
- Automated packaging line pusher mechanisms
- Plastic injection molding ejector systems
- CNC machine tool clamping devices
- Automotive assembly line positioning units
Installation Guidelines:1. Align cylinder axis within ±0.5° of load direction
2. Maintain 0.5-1mm clearance between rod end and load during mounting
3. Use clean dry air with 40μm filtration (dew point -20℃ below ambient)
4. For vertical mounting, install air vents upward to prevent condensate accumulation
| Property | Property Value |
|---|---|
| sku | SCF40X250-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <250MM> → <250mm> |
