Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X300-08A
AirTAC SCF Standard Tie-Rod Cylinder with Valve - SCF40X300-08A Specifications
- Model: SCF40X300-08A
- Type: Double-acting tie-rod cylinder with integrated 3/2-way solenoid valve
- Bore size: 40mm
- Stroke: 300mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Port size: G1/8 (ISO228 standard)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Valve type: Direct-acting 3/2-way normally closed
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Seal material: Nitrile rubber (NBR) with wear-resistant piston ring
- Temperature range: -20℃ to 80℃ (non-freezing)
- Weight: 2.5kg (including valve and mounting accessories)
- Dimensions: 408mm(L) × 52mm(W) × 52mm(H) (extended length: 708mm)
- Rod thread: M16×1.5
- Mounting type: Basic (no pre-mounted brackets)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty industrial cylinder featuring a compact valve-integrated design that reduces piping complexity. The anodized aluminum construction provides corrosion resistance, while the chrome-plated piston rod ensures durability in high-cycle applications. Includes magnetic piston for position sensing compatibility (sensor not included). Requires filtered air with 5-50μm particles and ISO VG32 lubricator oil.
- Press machine ejection systems
- Automated conveyor gate controls
- Plastic injection molding ejectors
- Automotive welding fixture actuation
- Packaging machine clamp positioning
Installation guidelines:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
For vertical mounting, use locking nuts on piston rod threads. Lubricate through
air supply at 1/3000 oil mist ratio. Avoid side-load forces exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SCF40X300-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 300mm |
