Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X350-08A
AirTAC SCF Standard Tie-Rod Cylinder with Valve (SCF40X350-08A) Specifications
- Model: SCF40X350-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40mm
- Stroke: 350mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G1/8 (ISO228/1 standard)
- Valve type: Internal pilot operated
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Seal material: HNBR (Hydrogenated Nitrile) with wear-resistant ring
- Protection rating: IP67 (valve section), IP54 (cylinder)
- Weight: 2.8kg (with valve)
- Dimensions:
- Extended length: 655mm
- Retracted length: 305mm
- Body diameter: 56mm
- Mounting bracket width: 25mm
Heavy-duty tie-rod cylinder featuring integrated valve for space-constrained installations. The chromium-plated piston rod and anodized aluminum barrel ensure corrosion resistance in humid environments. Designed for 1 million cycle durability with <2mm/m anti-rotation accuracy. Includes magnetic piston for position sensing compatibility.
- High-load press machinery ejection systems
- Automotive welding fixture clamping
- Plastic injection molding machine core pulling
- Conveyor gate actuation in food processing
- Paper roll clamping in printing equipment
Installation note:
Maintain 50mm clearance around valve manifold for heat dissipation.
Lubricate through integrated grease nipple (M6×1) every 3,000km of stroke
movement using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SCF40X350-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 350mm |
