Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X400-08A
AirTAC SCF Standard Cylinder Tie-Rod Type with Valve SCF40X400-08A Specifications
- Model: SCF40X400-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40mm
- Stroke: 400mm
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G1/8 (ISO228 standard)
- Valve type: Monostable with spring return
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP67 (valve section), IP65 (cylinder)
- Weight: 2.8kg (excluding accessories)
- Dimensions: 500mm(L) × 80mm(W) × 80mm(H) (fully retracted)
- Max piston speed: 500-800 mm/s (with cushion)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km)
Heavy-duty industrial cylinder featuring integrated valve mounting for space-saving installations. The chrome-plated piston rod and aluminum alloy construction ensure corrosion resistance in harsh environments. Includes magnetic piston for position sensing compatibility. Designed for high-cycle applications with 50,000km service life under standard conditions.
- Automated production line material handling
- Die-casting machine ejection systems
- Plastic injection molding clamp units
- Automotive welding fixture positioning
- Packaging machine vertical lift mechanisms
Installation guidelines:
Mount using provided tapped holes (M6×1.0 thread). Maintain 0.5mm minimum
clearance between magnetic sensor and cylinder body. Use AirTAC ISO VG32
lubricant for maintenance. Avoid side load exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | SCF40X400-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <400mm> |
