Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X450-08A
$109.77
Regular price
$117.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SCF40X450-08A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SCF Standard Tie-Rod Cylinder with Integrated Valve
1. A derivative series combining standard cylinder and valve configurations, compatible with 4M210 and 4M310 valves. Bore sizes 32/40/50 paired with 4M210 valves; bores 63/80/100 paired with 4M310 valves.
2. Enables 1:1 control logic without requiring additional external control valves.
3. Reduces installation time and space requirements, optimized for decentralized applications in large-scale systems.
4. Supports flexible integration with multiple mounting accessories and simplified installation processes.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SCF
Installation note:
Ensure proper alignment (≤0.2mm/m deviation) and use M8 mounting bolts (torque 25N·m).
For vertical mounting, install valve manifold horizontally to prevent condensate ingress.
AirTAC SCF Standard Tie-Rod Cylinder with Valve (SCF40X450-08A) Specifications
- Model: SCF40X450-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 450mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable pneumatic cushion at both ends
- Valve type: 5/2-way single solenoid with manual override
- Voltage options: DC24V (±10%) / AC220V (50/60Hz)
- Port size: PT1/4 (G1/4 optional)
- Mounting: Basic fixed (ISO 15552 foot mounting compatible)
- Material: Barrel (aluminum alloy), Piston rod (hard chrome-plated steel)
- Seal material: NBR (Nitrile) with wear-resistant guide rings
- Weight: ~3.8kg (without accessories)
- Dimensions: 550mm(L) × 82mm(W) × 82mm(H) (extended length)
- Protection rating: IP67 (valve section), IP40 (cylinder)
- Response time: ≤50ms (valve switching)
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-force industrial cylinder featuring integrated valve technology for space-efficient automation solutions. The hardened piston rod and multi-lip seals ensure 3,000km+ service life under full load. Designed for heavy-duty cycling (up to 5Hz) with <2mm cushioning adjustment range. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Metal stamping press ejection systems
- Plastic injection molding machine clamps
- Palletizing robot end-effectors
- Automotive welding fixture positioning
- Packaging machine compression units
Installation note:
Ensure proper alignment (≤0.2mm/m deviation) and use M8 mounting bolts (torque 25N·m).
For vertical mounting, install valve manifold horizontally to prevent condensate ingress.
Service Interval:
- Relubricate every 500,000 cycles (using ISO VG32 hydraulic oil)
- Inspect rod seals every 6 months in high-humidity environments
- Replace cushion seals after 1 million full-stroke operations
| Property | Property Value |
|---|---|
| sku | SCF40X450-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 450mm |
