Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X50-08A
AirTAC SCF Standard Cylinder Tie-Rod Type with Valve SCF40X50-08A Specifications
- Model: SCF40X50-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Operating temperature: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushioning: Adjustable air cushion at both ends
- Valve type: Direct-acting with manual override
- Voltage options: DC12V/24V, AC110V/220V (50/60Hz)
- Response time: ≤50ms (at 0.5MPa)
- Seal material: NBR (Nitrile rubber)
- Cylinder body: Aluminum alloy (A6063-T5)
- Tie rod material: Carbon steel (Zn-plated)
- Weight: 1.25kg (excluding accessories)
- Dimensions: 130mm(L) × 56mm(W) × 56mm(H) (Fully retracted)
- ISO standard: ISO 6432 (Mounting dimensions compliant)
- Protection rating: IP54 (Dust-proof and splash-resistant)
Heavy-duty tie-rod cylinder with integrated directional control valve, featuring anti-rotation piston design and wear-resistant guide rings. The modular structure allows easy maintenance with visible position indicator. Requires 5μm filtered lubricated air (ISO 8573-1 class 3) and compatible with ISO VG32 hydraulic oil for lubrication.
- Automated material handling systems
- Plastic injection molding machine ejectors
- Textile machinery clamping devices
- Automotive assembly line positioning
- Food processing conveyor gate controls
Installation note:
Mount using front flange/bracket (NF40 pattern). Maintain minimum 30mm clearance around valve section for heat dissipation.
Lubricate through air supply (1 drop/3m³) or via dedicated lubrication port. Avoid side-load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SCF40X50-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
