Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X500-08A
AirTAC SCF40X500-08A Tie-Rod Cylinder with Integrated Valve Specifications
- Model: SCF40X500-08A
- Type: ISO 15552 compliant tie-rod cylinder with built-in 5/2-way solenoid valve
- Bore size: 40 mm
- Stroke: 500 mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: PT1/4 (G1/4 optional)
- Cushioning: Adjustable pneumatic cushion at both ends
- Valve type: Direct-acting with manual override
- Voltage options: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Mounting: Standard foot mounting (ISO 15552 MF1), optional flange/bracket
- Weight: 3.8 kg (with valve, excluding fittings)
- Dimensions: 650mm(L) × 52mm(W) × 52mm(H) (retracted length)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Response time: ≤0.1s (valve switching)
- Protection rating: IP67 (valve), IP40 (cylinder)
High-force industrial cylinder combining structural rigidity of tie-rod design with space-saving integrated valve technology. Features dual cushion adjustment screws for precise end-position deceleration control. The valve's low power consumption (2.5W) and LED status indicator enable energy-efficient operation and visual diagnostics.
- Automated assembly line clamping mechanisms
- Plastic injection molding ejector systems
- Material handling vertical lift gates
- Textile machinery tension control
- Automotive welding fixture positioning
Installation note:
Maintain ≤0.5mm alignment tolerance during mounting. Lubricate through air port using ISO VG32 hydraulic oil mist (0.3-1.0cc/min) for initial 500km stroke distance. Valve exhaust must face downward in dusty environments.
| Property | Property Value |
|---|---|
| sku | SCF40X500-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 500mm |
