Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X600-08A
AirTAC SCF40X600-08A Standard Tie-Rod Cylinder with Integrated Valve Specifications
- Model: SCF40X600-08A
- Bore size: 40mm
- Stroke: 600mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Valve type: Built-in 5/2-way solenoid valve (single coil)
- Voltage options: DC24V (±10%), AC110V/220V (±15%) 50/60Hz
- Port size: G1/8 (ISO standard)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (nitrile rubber)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel (Cr-Mo)
- Protection rating: IP67 (standard), IP69K optional
- Weight: Approximately 3.8 kg (without accessories)
- Dimensions: 700mm(L) × 80mm(W) × 80mm(H) (fully retracted)
High-rigidity tie-rod cylinder featuring integrated 5/2-way solenoid valve for space-efficient automation solutions. The extended 600mm stroke version employs dual piston guidance for enhanced stability in long-stroke applications. Includes wear-resistant rod seals and auto-switch ready design for position feedback.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- Material handling conveyor diverters
- Automotive welding fixture positioning
- Packaging machine pusher systems
Installation guidelines:
Mount using centerline trunnion brackets (ISO 15552 compatible).
Maintain 0.5-1.0mm alignment tolerance during installation.
Lubricate with ISO VG32 hydraulic oil for initial operation.
Recommended maintenance cycle: 5 million cycles or 2 years.
- Max side load capacity: 180N at full extension
- Max moment load: 35N·m (lateral), 50N·m (axial)
- Air quality requirement: ISO 8573-1:2010 Class 3.4.3
- Response time: ≤80ms (valve switching at 0.5MPa)
| Property | Property Value |
|---|---|
| sku | SCF40X600-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 600mm |
