Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X700-08A
AirTAC SCF Standard Tie-Rod Cylinder with Valve - SCF40X700-08A
- Model: SCF40X700-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40mm
- Stroke: 700mm
- Operating pressure: 0.05-1.0 MPa
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR (Nitrile rubber)
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Valve voltage: DC24V/AC110V/AC220V (selectable)
- Valve response time: ≤15ms
- Protection rating: IP67 (cylinder), IP65 (valve)
- Weight: 8.7kg (with valve)
- Dimensions:
- Length: 940mm (full extension)
- Body diameter: 56mm
- Mounting width: 40mm (clevis mount standard)
- Valve block size: 62mm × 42mm × 35mm
Heavy-duty industrial cylinder featuring integrated directional control valve for space-saving installations. The hard-anodized barrel provides exceptional wear resistance in high-cycle applications (up to 5 million cycles at 0.5 MPa). Includes magnetic piston for position sensing compatibility. Designed for ISO 15552 mounting standards with multiple accessory options.
- Automated welding fixture clamping systems
- Plastic injection molding machine ejectors
- Steel mill roller positioning mechanisms
- Automotive assembly line transfer units
- Packaging machine vertical lift actuators
Installation note:
Maintain ≤0.3mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use auxiliary guide mechanisms. Lubricate rod weekly in high-contamination environments (ISO VG32 recommended).
| Property | Property Value |
|---|---|
| sku | SCF40X700-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 700mm |
