Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X75-08A
AirTAC SCF Standard Cylinder Tie-Rod Type with Valve – SCF40X75-08A Specifications
- Model: SCF40X75-08A
- Type: Double-acting tie-rod cylinder with integrated 5/2-way solenoid valve
- Bore size: 40 mm
- Stroke: 75 mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR + polyurethane (high wear resistance)
- Port size: Rc1/8 (G1/8 optional)
- Valve type: Monostable with manual override
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Mounting: Standard foot mounting (ISO 15552 compatible)
- Protection rating: IP67 (dust/water resistant)
- Weight: 2.8 kg (with valve assembly)
- Dimensions: 175mm(L) × 54mm(W) × 54mm(H) (excluding mounting accessories)
Industrial-grade cylinder featuring integrated valve technology for space-optimized pneumatic systems. The hardened aluminum alloy construction ensures 5000km+ service life under full load. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- High-speed packaging line clamping mechanisms
- Automated welding fixture positioning
- Plastic injection molding ejector systems
- Conveyor gate control in food processing
- Automotive assembly tooling
Installation note:
Lubricate air supply with ISO VG32 oil mist (1 drop/m³). Avoid side load exceeding 30N.
For vertical mounting, use counterbalance valves. Cycle rate ≤5Hz.
| Property | Property Value |
|---|---|
| sku | SCF40X75-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 75mm |
