Airtac SCF Standard Cylinder Tie-Rod Type With Valve SCF40X800-08A
AirTAC SCF Standard Tie-Rod Cylinder with Valve (SCF40X800-08A)
- Model: SCF40X800-08A
- Type: Double-acting tie-rod cylinder with integrated valve
- Bore size: 40mm
- Stroke: 800mm
- Operating pressure: 0.15–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Mounting type: Basic front/rear flange (NF1/NFC)
- Valve type: 5/2-way single solenoid (with manual override)
- Voltage options: DC24V (±10%), AC110V/220V (±15%)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Protection rating: IP67 (valve section), IP54 (cylinder)
- Weight: 8.5kg (dry, without accessories)
- Dimensions: 1002mm(L) × 120mm(W) × 120mm(H)
High-rigidity tie-rod cylinder featuring integrated valve for space-efficient automation solutions. The extended 800mm stroke version utilizes dual piston rod guidance for enhanced moment resistance. Includes magnetic piston for position sensing compatibility (sensor not included). Requires 5μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- Long-stroke press machine ejection systems
- Automated warehouse vertical lift mechanisms
- Plastic injection molding machine core-pulling
- Heavy-duty clamping fixtures in automotive jigs
- Paper roll handling equipment
Installation note:
Requires rigid mounting surface with ≤0.1mm/m flatness. For vertical installations,
use auxiliary guide rails when handling asymmetric loads. Lubricate rod weekly
under high-cycle (>500k actuations/month) conditions.
| Property | Property Value |
|---|---|
| sku | SCF40X800-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Standard Voltage | AC220V |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 800mm |
