Airtac SCJ32 Standard Cylinder SCJ32X60-30
The AirTAC Airtac SCJ32 Standard Cylinder SCJ32X60-30 is a genuine double-acting SINGLE-ROD air cylinder with a rear-cap ADJUSTING SCREW: the stroke end is field-adjustable within a 30 mm range without swapping the cylinder. Ø32mm bore, 60mm nominal stroke, PT1/8 ports and adjustable end cushioning.
- BoreØ32 mm
- Nominal stroke60 mm
- Stroke adjust-30 mm
- Port sizePT1/8
- Rod threadM10×1.25
- CushionAdjustable, 21 mm
About the Airtac SCJ32 Standard Cylinder SCJ32X60-30
The SCJ32X60-30 is a double-acting, single-rod pneumatic cylinder with a field-adjustable stroke end, letting you fine-tune the 60 mm nominal stroke down by up to 30 mm without changing the cylinder. It delivers 402 N of push force at 0.5 MPa and 724 N at 0.9 MPa, using a 12 mm diameter piston rod and PT1/8 ports.
This 32 mm bore tie-rod cylinder includes an adjustable air cushion (21 mm length) for smooth deceleration and a rear adjusting screw for precise end-stop setting. The body length A is 182 mm, making it a compact choice for commissioning trials and format changeovers on light automation equipment.
Airtac SCJ32 Standard Cylinder SCJ32X60-30 Technical Specifications
| Model | Airtac SCJ32 Standard Cylinder SCJ32X60-30 |
|---|---|
| Series | SCJ adjustable-stroke tie-rod cylinder |
| Bore size | Ø32 mm |
| Nominal stroke | 60 mm |
| Stroke adjustment | Up to 30 mm (rear adjusting screw) |
| Acting type | Double acting (single rod) |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SCJ (adjustable-stroke) datasheet. The rear adjusting screw sets the stroke end position; force is the same as the equivalent single-rod SC bore. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
SCJ is single-rod, so force matches the equivalent SC bore: push uses the full bore area, pull subtracts the rod area. Actual usable force is lower than theoretical due to friction and back-pressure; size with a safety margin.
Model Code: Airtac SCJ32 Standard Cylinder SCJ32X60-30
| SCJ | Adjustable-stroke tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×60 | Nominal (maximum) stroke length in mm. |
| -30 | Adjustable-stroke range in mm (options 10/20/30/40/50/75/100). |
| -S | Optional built-in magnet for sensor position sensing. |
Related types: SC (single rod, fixed stroke), SCD (double rod), SCT (multi-position). SCJ mounting: Basic, FA, LB, TC, TCM1. Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SCJ32 Standard Cylinder SCJ32X60-30 Is Used
Commissioning & Trial Runs
The 30 mm adjustment range lets technicians fine-tune the actuator end position during machine setup without fabricating custom stops, speeding up line commissioning.
Small-Part Diverting
Adjust the stroke end to precisely align a diverter gate or pusher blade on a compact conveyor, accommodating different product widths on the fly.
Wear Take-Up on Clamps
Compensate for jaw or pad wear in light-duty clamping fixtures by advancing the stroke end with the rear screw, maintaining consistent grip force over time.
Is the Airtac SCJ32 Standard Cylinder SCJ32X60-30 the Right Cylinder?
Choose the SCJ32 when you need to dial in a stroke end position on a 32 mm bore platform without swapping hardware. If you require more push force, step up to the 40 mm bore SCJ40, which provides 628 N at 0.5 MPa. For applications where the stroke is fixed and never needs field adjustment, the standard SC32 fixed-stroke cylinder is a simpler, cost-effective alternative. To replace this model, match the 32 mm bore, 60 mm nominal stroke, 30 mm adjust range, PT port thread, and basic mounting style.
Adjustable-stroke checklist
- ✓ Need to fine-tune stroke on the line?
- ✓ Nominal stroke + adjust range (-30)
- ✓ Required force at your working pressure
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Set the rear adjusting screw, then lock it before running.
- check Adjust end cushion screws for smooth stops.
- check Use SCJ mounting accessory (FA / LB / TC / TCM1).
- check Installation by qualified personnel per AirTAC docs.
Airtac SCJ32 Standard Cylinder SCJ32X60-30 FAQ
At 0.5 MPa, the cylinder produces 402 N pushing and 345 N pulling. At the maximum operating pressure of 0.9 MPa, the push force reaches 724 N. The theoretical force at 1.0 MPa is 82 kgf.
A rear-cap adjusting screw lets you shorten the stroke end by up to 30 mm from the 60 mm nominal maximum. It sets the mechanical stop position for the piston, so you can fine-tune the extension length without altering the cylinder's bore or force rating.
