Airtac SCLF Front Locking Cylinder SCLF63X50-S
2. Release modes: Auto-release system and Manual override capability.
Category: Locking Pneumatic Cylinders , Brand: AIRTAC , Series: SCLF
AirTAC SCLF63X50-S Front Lock Cylinder Specifications
- Model: SCLF63X50-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø63mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.2–1.0 MPa
- Locking force: 1,850N (at 0.5MPa)
- Mounting style: Standard front flange (MF1)
- Cushion type: Adjustable air cushion (both ends)
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Weight: 3.2kg (excluding accessories)
- Dimensions: 236mm(L) × 80mm(W) × 80mm(H) (at mid-stroke)
- Protection rating: IP54 (standard), IP67 (optional)
- Piston speed: 50–800mm/s
Heavy-duty locking cylinder featuring fail-safe mechanical wedge locking mechanism activated by spring force. The dual-piston design ensures positive position holding even during power/pressure loss. Precision ground rod with triple chrome plating provides exceptional wear resistance. Includes magnetic piston for position sensing compatibility.
- Vertical load holding in automated assembly lines
- Safety clamping in die-casting machines
- Position retention in material handling elevators
- Emergency stop mechanisms in press equipment
- Precision fixturing for CNC machining centers
Installation note:
Requires minimum 0.3MPa air pressure for lock release. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃. Avoid side-load applications exceeding 50N.
- ±0.1mm repeat positioning accuracy
- 500km minimum service life (under standard conditions)
- Lock engagement time: <0.3s at 0.5MPa
- Vibration resistance: 10–55Hz, 1.5mm amplitude
| Property | Property Value |
|---|---|
| sku | SCLF63X50-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <50mm> |
| Lock Position | Front Cover with Lock |
