Airtac SDA Ultra Thin Cylinder SDA100X35
2. Features riveted structure between cylinder body/rear cover and piston/piston rod, ensuring compactness and reliability;
3. Cylinder bore undergoes roller burnishing followed by hard anodizing treatment for superior wear resistance and durability;
4. Asymmetrical bidirectional sealing structure on piston provides compact dimensions with integrated oil reservoir functionality;
5. Space-saving design optimizes installation footprint;
6. Peripheral T-slots for magnetic sensors enable convenient switch mounting;
7. Multiple model variations available across comprehensive specifications.
Category: Slim Cylinders , Brand: AirTAC , Series: SDA
AirTAC SDA Ultra-Thin Cylinder SDA100X35 Technical Details
- Model: SDA100X35
- Bore size: Ø100mm
- Stroke: 35mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Cushioning: Adjustable rubber buffer
- Mounting type: Foot-mounted (MF1) with optional front flange
- Rod material: Hard chrome-plated steel
- Seal type: NBR + PU hybrid seals
- Weight: 1.85kg (bare cylinder), 2.1kg (with accessories)
- Dimensions: 135mm(L) × 112mm(W) × 112mm(H)
- ISO standard: 6432 compliant
- Protection class: IP54 (standard), IP67 (optional)
Ultra-low profile cylinder optimized for space-constrained automation systems. Features dual-piston guidance for enhanced moment resistance and anti-rotation stability. The anodized aluminum body with integrated mounting slots enables tool-free adjustments. Compatible with vacuum applications when paired with special seals.
- High-density pick-and-place systems in semiconductor manufacturing
- Clamping mechanisms in CNC fixture tooling
- Vertical lift assists in pharmaceutical packaging lines
- Compact actuator for cleanroom robotics
- Pressurization systems in food processing equipment
Installation tip:
Maintain 0.5mm minimum clearance between piston rod and guide mechanisms.
Use alignment jigs during mounting to prevent side load deformation.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SDA100X35 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 35mm |
